GAC Engine Speed Control Unit Speed Controller Droop Governor 3044196
Model: 3044196
GAC Engine Speed Control Unit Speed Controller Droop Governor 3044196 ,factory price with CE verified.
| Warranty | 13 months |
|---|---|
| Place of Origin | Fujian, China |
| Brand Name | POPULACE |
| Model Number | 3044196 |
| Working Voltage | 24±8V DC |
| Output Current Range | 0-2.5A |
GAC Engine Speed Control Unit Speed Controller Droop Governor 3044196
 | GAC Engine Speed Control Unit Speed Controller Droop Governor 3044196 Speed Controller 3044196 Electronic Governor For Generators is PID adjustment design. It can instant and accurately reaction to the transient change of the loading then to make the engine speed in stable situation. It can perfectly control the engine speed by connected to the EFC series Electronic Acuator and Speed Sensor. |
 | Features * 24 VDC ±20% * Negative Ground (Case Isolated) * 40 MA * 4.5 A continuous * 2-120 Volts RMS |
| 3044196 Speed Regulator | ||
| Input | Supply | 24 VDC ±20% |
| Polarity | Negative Ground (Case Isolated) | |
| Power Consumption | 40 MA | |
| Maximum Actuator Current | 4.5 A continuous | |
| Speed Sensor Signal | 2-120 Volts RMS | |
| Performance | Isochronous Operation /Steady State Stability | ±0.25% or better |
| Speed Range/Governor | 1K to 6.5K Hz continuous | |
| Speed Drift with Temperature | ±1 Max | |
| Idle Regulation | 260±20 Hz | |
| Droop Adj. Max. | 400 Hz.,±75Hz. Per 1.0A change | |
| Speed Trim Range | ±200 Hz with 1 ohm connected | |
| Remote Variable Speed Range | 25 to 100% of rated speed | |
| Impedance | 1m ohms | |
| Environmental | Ambient Operating Temperature Range | -40 to +85 Deg. C |
| Relative Humidity | Up to 95% | |
| All Surface Finishes | Fungus Proof and Corrosion Resitant | |
| Reliability | Vibration | 20 to 100 Hz. 500mm/sec |
